360 Suction Base
The Quad Lock Suction Base offers high-strength, repositionable suction for versatile mounting on smooth, non-porous surfaces like windshields and dashboards. Ideal for marine, aero, and drive applications, it withstands temperatures from -10°C to 50°C (14°F to 122°F) without losing suction. For optimal use, pair with an ARM and HEAD for sufficient clearance for the lever, unless combining with the Action Camera Head, which allows sufficient clearance without the need for an arm.
Tutorials
FAQ
What's Included?
1 x Quad Lock 360™ Suction Base
How do I reposition the Suction Base?
1.) Rotate the lever upwards to unlock the suction cup. 2.) Check that both the surfaces of the suction cup and the substrate are free from dust and dirt. 3.) Re-apply the suction cup.
How much weight will the Suction Base hold?
The Suction Base is capable of supporting loads of up to 1.2kg through typical use cases.
Can the Suction Base be used in planes or helicopters? Are there any required certifications?
Yes, the Suction Base can be used in aviation applications, up to an altitude of 10,000 feet. Certifications are not required as the Suction Base is not a fixed device.
What activities / applications are NOT recommended for the Suction Base?
The Suction Base is not recommended for use on motorcycles, scooters, ATVs, or other high frequency engine vibration applications.
Are replacement / spare parts available for the Suction Base?
There are no spare parts available for the Suction Base. In case of damage, please reach out to our Customer Support team for assistance.
Does the Suction Base fit inside our Dash Pad?
No, the base is wider than the base of the Windscreen/Dash Mount and will not fit inside the Dash Pad.
What surfaces will the 360 Suction Base adhere to?
The Suction Base can be attached to a number of different flat and gently curved surfaces, however, it is not intended for severely curved surfaces (ie. <1m curvature radius).
The Suction Base will adhere to smooth, non-textured, non-porous surfaces such as:
Recommended applications:
It is not recommended for the following substrates:
Although possible, we do not recommend using the Suction Base on the following vehicles:
Clean the surface with a damp cloth and allow it to dry before attaching.
Ensure the mount position does not obstruct vehicle safety features such as airbags.
Can I purchase the 360 Suction Base as part of a kit?
The 360 Suction Base can be purchased within the 360 kit builder or separately along with all of our 360 compatible products.
Tech Specs
360 Suction Base
- Suits smooth, non-porous surfaces (>1m curvature radius)
- Suits flat and slightly curved surfaces
- Suction cup is durable and repositionable
- Easy-to-use locking and unlocking lever
- Glass filled nylon housing
- Quad Lock 360™ ARM not required when combining with the Quad Lock 360™ Action Camera Head
- Quad Lock 360™ ARM required with all other HEADS to ensure enough clearance for locking and unlocking the Suction Base
- -10°C to +50°C (14°F to 122°F) ambient / outside temperature
- Supports up to 1.2kg (2.64 pounds)
- Weight: 100 grams (3.52 oz)
Dimensions
