12V-24V Waterproof Wireless Charging Head

The Quad Lock 12V - 24V Waterproof Wireless Charging Head provides secure, cable-free charging while riding in all weather conditions. It connects easily to your motorcycle, keeping your phone charged without the need for cables. For proper installation, it must be wired through the ignition positive (not steady positive) or an isolator switch with the correct in-line 3A fuse, and should not be connected directly to the battery to prevent drain. Professional installation is recommended.
Tutorials
FAQ
Whats Included?
- 1 x Quad Lock® 12V-24V Waterproof Wireless Charging Head with 1.5m hardwired cable with fly leads
- 2 x Cable grommet plugs
- 1 x 3mm hex (Allen) key
- 1 x M5 x 35mm CSK hex socket screw
- 5 x 5mm x 200mm nylon zip ties
What Mounts does the 12V-24V Waterproof Wireless Charging Head fit?
The charging head fits all our 360/Marine mounts and mounts which feature our index connecting feature such as our Motorcycle Mounts.
Is the Wireless Charger compatible with the vibration dampener?
Yes, these products are compatible and a super common combination!
Will it drain my battery?
This charger can drain your battery if not installed correctly. It's important that the Hardwired Waterproof Wireless Charging Head is connected to an ignition positive wire, as it will continue to draw power from the battery if connected directly to the battery or a steady positive wire.
If connected to the ignition positive wire of the vehicle, it will only draw power once the ignition is switched on.
Can I install this charger on a motorcycle?
Absolutely, this charger is suitable for motorcycles with no available USB Port or USB Power Supply.
However it's important that the charger is installed via the ignition positive wire and not the steady positive (directly to battery) so as to not drain the bike's battery.
What does the LED indicate?
Tech Specs
Waterproof Wireless Charging Head
- Dual stage lock
- Aluminium rear housing and tough glass filled nylon front
- IP67 Water Resistant
- 1.5m hardwired cable with fly leads
- Input: Hardwired to 12V or 24V battery
- Output: 5W / 7.5W / 10W / 15W (iPhone up to 7.5W)
- Red LED light for status indication
- Portrait or landscape mounting for optimal viewing
- Weight: 232 grams (8.18 oz)
Dimensions
