Mirror Stem Mount & Adaptor Kit
The Quad Lock Mirror Stem Mount securely installs between your scooter or motorcycle's mirror stem and interface. Featuring an offset, angled arm for optimal viewing and a gimbal pivot head for easy angle adjustments, it ensures a secure fit without tools. The anti-theft gimbal head prevents disassembly, while the sleek, minimal design seamlessly integrates with your bike. For extra clearance, add the Mirror Stem Mount Adaptor Kit.
Tutorials
FAQ
Whats Included?
- 1 x Quad Lock® Index Head (with blue lever)
- 1 x Quad Lock® Mirror Stem Mount
- 1 x M8 Shoulder Washer
- 1 x M10 Flat Washer
- 1 x 3mm Hex (Allen) Key
Optional Extras
- M10 x 1.25 thread pitch
- M10 x 1.25-LH (reverse) thread pitch
- M10 x 1.5 thread pitch
- M8 x 1.25 thread pitch
Where do you mount the Mirror Stem Mount on a motorcycle or scooter?
The Mirror Stem Mount is sandwiched between the mirror shaft and the mirror shaft mount interface. The Mirror Stem Mount can be assembled on the left hand or right hand side of the motorcycle.
What tools do you need to assemble the Mirror Stem Mount?
We recommend using a spanner to tighten the existing lock nut on the mirror shaft. Adjust the lock nut to ensure there is a minimum of 10mm of thread length before assembly.
Will the Mirror Stem Mount fit on all motorcycles?
The Motorcycle mount interface can vary significantly with trim profile, position of handlebar controls and surrounding components such as the clutch and brake reservoir. If required use a QL adapter to raise the mount interface to provide clearance to surrounding components and trim. QL adapters are sold separately as an Accessory.
Where does the adapter fit on a motorcycle/scooter?
The adapter is screwed into the existing Mirror shaft thread to raise the mount interface above surrounding trim, handlebar controls or the clutch and brake reservoir mount. They can be mounted on the lh or rh side of a motorcycle/scooter
What Motorbikes will the adapters fit?
The adapter thread sizes are the most common sizes found on motorcycles and appeal to a broad range of motorbikes. There are 4 adapters in the kit with 3 different thread sizes. The thread pitch is common to both the male and female thread on each adapter. M10 x 1.25 & M10 x 1.25 LH - Left hand thread M10 x 1.5 - BMW M8 x 1.25 - Smaller scooters. Piaggio
Is the Mirror Stem Mount 360 compatible?
Yes, the Mirror Stem Mount is compatible with any of our 360 heads and arms. Since it's part of our 360 range, all components are interchangeable with other 360 parts, allowing you to customise it to suit your needs. You can even build and personalise your setup using our 360 Kit Builder tool, available on our website here.
Tech Specs
Mirror Stem Mount
- Made from diecast aluminium
- Secure mounting to the mirror shaft
- Suit an M10 or M8 thread mirror arm
- The offset, angled arm allows for clearance to components and trim in various installation setups
- Mount on the left or right hand side
- Tool free gimbal pivot head adjustment
- Weight: 110 grams (3.88 oz)
Mirror Stem Mount Dimensions
Mirror Stem Mount Adaptor kit
- Raise in mirror shaft interface by 20mm (0.79")
- Made from high-tensile steel
- Threadlocker for secure fastening
- Compatible with Mirror Stem Mount only
- Weight: 7 grams (0.24 oz)
Mirror Stem Mount Adaptor kit Dimensions
