Single and Dual Pivot Arms
The Dual Pivot Arm offers optimal viewing with adjustable positioning. Available in small (51mm) and medium (75mm) sizes, it includes a hex screw for security or a thumb screw for easy adjustments. Compatible with all Quad Lock 360 Heads and Bases, it ensures secure positioning with preload tension. The Single Pivot Arm provides similar flexibility with a single pivot point for simpler adjustments.
Tutorials
FAQ
What's Included?
Dual Pivot Arm
- 1 x Dual Pivot Arm (51mm or 75mm) (2" or 3")
- 1 x Thumb Screw (to replace Hex Screw)
- 1 x 3mm Hex Key
Single Pivot Arm
- 1 x Single Pivot Arm
- 1 x 3mm Hex Key
What is the difference between the Single Pivot Arm & Knuckle Adapter? They seem to do the same thing and the Single Pivot is slightly more expensive?
The main point of difference between both products is the ease & flexibility of use;
What is the ball dimensions in our Dual Pivot Arms
22mm
Can I combine multiple arms, for example, an extension arm and a small dual-pivot arm?
Yes since all the arms have 360 connections on them you could theoretically link as many arms together as you’d like, though it's worth considering the leverage that this will place on the base of the mount once a phone is attached.
Can I use a Dual Pivot Arm with my existing ball mount from a 3rd party brand?
The Dual Pivot Arms contain 22mm pivot balls, which aren't interchangeable with most ball mounts on the market which typically come in 25mm.
How can I get more adjustability on my motorcycle mount?
If you're installing our Handlebar Mount on angled bars or just want more adjustability from your motorcycle mount, the Quad Lock Knuckle Adaptor or 360 Single Pivot Arm might be just what you're looking for.
You can achieve twice the adjustability with one of our 360 Dual Pivot Arms. The two ball heads at either end also offer 180 degrees and 360 degrees movement for greater angle options.
These come in two different sizes and feature a thumb screw for easy adjustment on the go, or a hex screw for anti-theft protection.
Can the Dual and Single pivot arms be purchased as part of a kit?
The Single, and Dual Pivot Arms, can both be purchased within the 360 kit builder or separately along with all of our 360 compatible products.
Can I purchase replacement balls for the Dual Pivot arms?
Yes, replacement balls can be purchased here.
Tech Specs
Single Pivot Arm
- The Single Pivot Arm is made from tough, nylon construct.
- The outside diameter of the tightening nut is 40mm (1.57") and it stands at 45.5mm (1.8") tall.
- Compatible with all Quad Lock 360 BASES and HEADS
- Weight: 37 grams (1.30 oz)
Single Pivot Arm Dimensions
Dual Pivot Arms Small and Medium
- Arms made from tough, glass filled nylon
- Designed with preload tension for easy adjustability
- Two sides of the Dual Pivot Arms feature grooves to allow for tidy cable management
- 22mm (7/8") Balls
- Small Arm - length: 51mm (2") pivot-to-pivot
- Medium Arm- length: 75mm (3") pivot-to-pivot
- Small Arm - Weight: 79 grams (2.78 oz)
- Medium Arm - Weight: 101 grams (3.56 oz)
Dual Pivot Arms Small and Medium Dimensions
